Name: ZALMAN SF120 - Kabinettvifte - 120 mm
SKU: 6083333
Price: 283 NOK
Availability: InStock

ZALMAN SF120 - Kabinettvifte - 120 mm | SKU: ZM-SF120 | Brand: Zalman | EAN: 8809213769627<br>

color

weight

Ytelse

Locations in which the product can be used.

Egnet plassering

Modell/Type

Viftediameter

The lowest frequency at which the rotating component operates, measured in revolutions per minute.

Rotasjonshastighet (min)

The maximum frequency at which the rotating part of the device completes a full turn, typically measured in revolutions per minute (rpm).

Rotasjonshasrighet (max)

How loud the device is when used at high speed.

Støynivå (høy hastighet)

The highest volume of air the device can move per unit of time, typically measured in cubic feet per minute (CFM) or cubic metres per hour (m³/h).

Maksimal luftstrøm

The highest amount of air pressure the unit can generate, measured in mmH2O.

Maksimalt lufttrykk

Indicates whether the device supports pulse-width modulation for controlling power delivery or signal intensity.

Pulsbreddemodulerings- støtte (PWM)

The mechanical design used to reduce friction between moving parts, such as a ball bearing or fluid dynamic bearing.

Lagertype

Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism.

Gjennomsnittstid mellom feil (MTBF)

Design

Produktfarge

The quantity of fans (apparatus with rotating blades that creates a current of air for cooling or ventilation).

Antall vifter

The total count of individual blades attached to the impeller or rotor used to move air.

Antall vifteblader

Indicates whether the product features integrated LED lighting for visibility or aesthetic purposes.

Belysningsdiode

Belysningsfarge

The type and number of pins on the interface used to provide power and control signals to the connected component (e.g., 4-pin).

Viftetilkobling

Specifies the official standards, safety approvals, or regulatory certifications the product has received.

Sertifisering

Energihåndtering

The electrical potential difference required for the operation of the device, typically measured in volts (V).

Spenning

The maximum amount of electric current the device is designed to carry continuously under specified conditions, measured in amperes.

Nominell linjestrøm

Vekt og dimensjoner

The measurement or extent of something from side to side.

Bredde

The distance from the front to the back of something.

Dybde

The measurement of the product from head to foot or from base to top.

Høyde

Weight of the product without packaging (net weight). If possible

Vekt

Tekniske detaljer

Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.

Samsvarssertifikat

Emballasjeinnhold

Indicates whether the necessary screws for installation or assembly are provided with the product.

Skruer inkludert

The total quantity of screws included with the product for assembly or installation.

ZALMAN SF120 - Kabinettvifte - 120 mm

283 kr

283 kr

Produktbeskrivelse

ZALMAN SF120 - Kabinettvifte - 120 mm

283 kr

283 kr

Ytelse
Egnet plassering	PC-kjølevifte
Modell/Type	Vifte
Viftediameter	12 cm
Rotasjonshastighet (min)	800 RPM
Rotasjonshasrighet (max)	1500 RPM
Støynivå (høy hastighet)	28 dB
Maksimal luftstrøm	54 cfm
Maksimalt lufttrykk	1,1 mmH2O
Pulsbreddemodulerings- støtte (PWM)	Ja
Lagertype	Fluid Dynamic Bearing (FDB)
Gjennomsnittstid mellom feil (MTBF)	100000 timer

Design
Produktfarge	Svart
Antall vifter	1 vifter
Antall vifteblader	9
Belysningsdiode	Ja
Belysningsfarge	Blå, Grønn, Rød
Viftetilkobling	3-pin + 4-pin
Sertifisering	CE

Energihåndtering
Spenning	5-12 V
Nominell linjestrøm	0,2 A

Vekt og dimensjoner
Bredde	120 mm
Dybde	120 mm
Høyde	26 mm
Vekt	100 g

Tekniske detaljer
Samsvarssertifikat	RoHS

Emballasjeinnhold
Skruer inkludert	Ja
Antall skruer	4
