Prosessorprodusent

AMD

Prosessorstøpsel

Sokkel AM5

Kompatible prosessorserier

AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series

Støttede minnetyper

DDR5-SDRAM

Antall minnespor

4

Minnesportype

DIMM

Minnekanaler

Tokanals

ECC-kompatibilitet

ECC & ikke-ECC

Støttet minneklokkehastighet (maks.)

8000 MHz

Maksimalt internminne

256 GB

Ubufret minne

Ja

Støttet lagrings drive type

HDD & SSD

Støttede lagringsgrensesnitt

M.2, SATA III

Antall støttede HDDer

2

Antall lagringsdrivere som støttes

6

RAID-støtte

Ja

RAID-nivåer

0, 1, 5, 10

Støtter parallellprosesseringsteknologi

Støttes ikke

USB 2.0-tilkoblinger

2

USB 3.2 Gen 1 (3.1 Gen 1)-kontakter

1

USB 3.2 Gen 2 (3.1 Gen 2)-kontakter

1

Antall SATA III-tilkoblinger

2

Lydtilkobling på fremsiden

Ja

Frontpanelkontakt

Ja

ATX strømtilkobling (24-pin)

Ja

CPU viftetilkobling

Ja

Antall CPU-viftekontakter

1

Antall understellsviftetilkoblinger

3

Understell inngrepstilkobling

Ja

EPS strømtilkobling (8-pin)

Ja

12V strømkontakt

Ja

Antall USB 2.0-porter

2

Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter

4

Antall USB 3.2 Gen 2 (3.1 Gen 2) Type-A-porter

2

Antall USB 3.2 Gen 2 (3.1 Gen 2)Type-C-porter

1

Antall USB 3.2 Gen 2x2 Type C-porter

1

Antall ethernets-/bredbåndstilkoblinger (RJ-45)

1

Antall HDMI-porter

1

Antall DisplayPorts

1

Mikrofon, linje-inn-støpsel

Ja

S/PDIF-utport

Ja

WiFi-AP antennestøpsel

2

Ethernet/bredbåndsforbindelse

Ja

Ethernet-grensesnittype

2.5 Gigabit Ethernet

Wi-Fi

Ja

Beste Wi-Fi-standard

Wi-Fi 7 (802.11be)

Wi-Fi-standarder

Wi-Fi 7 (802.11be)

Bluetooth

Ja

Bluetooth-versjon

5.4

Systemkort kretsoppsett

AMD B850

Lyd-utgang kanaler

7.1 kanaler

Produktfarge

Hvit

Komponent for

PC

Hovedkort formfaktor

Micro ATX

Hovedkort-chipsettfamilie

AMD

Støttede Windows operativsystemer

Windows 11

PCI Express x16 (Gen 5.x) spor

1

Antall M.2 (M)-spor

4

BIOS-type

UEFI AMI

BIOS minnestørrelse

256 Mbit

Clear CMOS-knapp

Ja

Pakkebredde

285 mm

Pakkedybde

277 mm

Pakkehøyde

72,5 mm

Bredde

244 mm

Dybde

244 mm

Antenne inkludert

Ja

Lydutgang

Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC*
- Impedance sense for front and rear headphone outputs
- Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
- Supports up to 32-Bit/192 kHz playback*
Audio Features
- SupremeFX Shielding Technology
- Savitech SV3H712 AMP
- Rear optical S/PDIF out port
- Premium audio capacitors
- Audio cover
*A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.

Spesielle funksjoner

Total supports 4 x M.2 slots and 2 x SATA 6Gb/s ports*
AMD Ryzen™ 9000 & 7000 Series Desktop Processors*
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
AMD Ryzen™ 8000 Series Desktop Processors*
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4/x2 mode)

AMD B850 Chipset
M.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4)
M.2_4 slot (Key M), type 2280 (supports PCIe 4.0 x4) on the underside of the board

2 x SATA 6Gb/s ports
*Specifications vary by CPU types.

Andre egenskaper

4 x DIMM slots, max. 256GB, DDR5
Supports up to 8000+MT/s(OC) with Ryzen™ 9000 & 8000 & 7000 Series Processors
ECC and Non-ECC Un-buffered DIMM
Dual channel memory architecture
Supports AMD Extended Profiles for Overclocking (EXPO™)
ASUS Enhanced Memory Profile (AEMP)
* Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/download-center/. Adjustments will be made based on the specifications of mass-produced memory products available on the market.
**Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.

Grafikkutgang

1 x DisplayPort**
1 x HDMI™ port***
* Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications.
** Supports max. 8K@30Hz as specified in DisplayPort 1.4.
*** Supports 4K@60Hz as specified in HDMI 2.1.
**** VGA resolution support depends on processors' or graphic cards' resolution.
