Name: LED Driver PWM-120-24, 24VDC 5A 120W, IP67
SKU: 3440023
Price: 684 NOK
Availability: InStock

LED Driver PWM-120-24, 24VDC 5A 120W, IP67 | SKU: PWM-120-24 | Brand: Mean Well | EAN: 4711287460079<br>

color

weight

Egenskaper

Formål

The type of power supply which this product uses.

Type strømforsyning

Specifies the direction of electrical current conversion, such as from alternating current to direct current (AC to DC) or vice versa.

Strømtype

The voltage (V) which is required to power the product.

Inngangsspenning

The frequency (Hz) which is required to power the product.

Inngangsfrekvens

The amount of electrical current drawn by the device during operation, typically measured in amperes (A) or milliamperes (mA).

Innput-strøm

Utgangseffekt

The electrical potential difference delivered by the device, typically expressed in volts (e.g. 24-48).

Utgangsstrøm

The maximum electrical current that the device can provide to a connected load, measured in amperes (A).

The percentage of input energy that is converted into useful work or output, rather than being lost as heat or waste (e.g. 92%).

Effektivitet

Features that protect the device against power problems e.g. overload.

Strømbeskyttelsesfunksjoner

Ytelse

Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism.

Gjennomsnittstid mellom feil (MTBF)

Design

Produktfarge

Miljømessige forhold

The minimum and maximum temperatures at which the product can be safely operated.

Driftstemperatur (T-T)

The minimum and maximum temperatures at which the product can be safely stored.

Oppbevaringstemperaturomåde (Celsius)

The range of relative humidity, expressed as a percentage, within which the device can function correctly without damage or performance loss.

Relativ luftfuktighet under drift (H-H)

The permissible range of relative humidity, expressed as a percentage, within which the product can be stored without damage.

Egenskaper
Formål	Lysstrimmel
Type strømforsyning	Universell
Strømtype	AC-to-DC
Inngangsspenning	90-305 V
Inngangsfrekvens	47/63 Hz
Innput-strøm	1.3 A
Utgangseffekt	120 W
Utgangsstrøm	24 V
Utgangsstrøm	5 A
Effektivitet	90%
Strømbeskyttelsesfunksjoner	Over-spenning (volt), Overoppheting, Overbelastning, Kortslutning

Ytelse
Gjennomsnittstid mellom feil (MTBF)	860400 timer

Design
Produktfarge	Svart

Miljømessige forhold
Driftstemperatur (T-T)	-40 - 90 °C
Oppbevaringstemperaturomåde (Celsius)	-40 - 80 °C
Relativ luftfuktighet under drift (H-H)	20 - 95%
Lagringsrelativ fuktighet	10 - 95%

Vekt og dimensjoner
Bredde	63 mm
Dybde	191 mm
Høyde	37,5 mm
Vekt	970 g
