Svitsjtype

Håndtert

Strømbryterbelegg

L2/L3

Quality of Service (QoS) støtte

Ja

Skyadministrert

Ja

ARP-inspeksjon

Ja

Configuring Location Settings (CLI)

Ja

Systemhendelseslogg

Ja

MIB-støtte

RFC 1155 SMI RFC 1157 SNMPv1 RFC 1212, RFC 1213, RFC 1215 MIB-II, Ethernet-Like MIB and TRAPs RFC 1493 Bridge MIB RFC 1643 Ethernet MIB RFC 1657 BGP-4 MIB RFC 1724 RIPv2 MIB RFC 1850 OSPFv2 MIB RFC 1905 RFC 1907 SNMP v2c, SMIv2 and Revised MIB-II RFC 2011 SNMPv2 for Internet Protocol using SMIv2 RFC 2012 SNMPv2 for transmission control protocol using SMIv2 RFC 2013 SNMPv2 for user datagram protocol suing SMIv2 RFC 2096 IPv4 Forwarding Table MIB RFC 2287 System Application Packages MIB RFC 2570–2575 SNMPv3, user based security, encryption, and authentication RFC 2576 Coexistence between SNMP Version 1, Version 2 and Version 3 RFC 2578 SNMP Structure of Management Information MIB RFC 2579 SNMP Textual Conventions for SMIv2 RFC 2665 Ethernet-like interface MIB RFC 2787 VRRP MIB RFC 2819 RMON MIB RFC 2863 Interface Group MIB RFC 2863 Interface MIB RFC 2922 LLDP MIB RFC 2925 Ping/Traceroute MIB RFC 2932 IPv4 Multicast MIB RFC 3413 SNMP Application MIB RFC 3414 User-based Security model for SNMPv3 RFC 3415 View-based Access Control Model for SNMP RFC 3621 PoE-MIB (PoE switches only) RFC 4188 STP and Extensions MIB RFC 4363 Definitions of Managed Objects for Bridges with Traffic Classes, Multicast Filtering, and VLAN extensions RFC 5643 OSPF v3 MIB support Draft – blumenthal – aes – usm - 08 Draft – reeder - snmpv3 – usm - 3desede -00 Draft-ietf-bfd-mib-02.txt Draft-ietf-idmr-igmp-mib-13 Draft-ietf-idmr-pim-mib-09 Draft-ietf-idr-bgp4-mibv2-02.txt – Enhanced BGP-4 MIB Draft-ietf-isis-wg-mib-07

Antall Basic switching RJ-45 Ethernet-ports

12

Basic switching RJ-45 Ethernet ports-type

Gigabit Ethernet (10/100/1000)

SFP+ module antall spor

4

Antall uplink-porter

2

Konsollport

RJ-45

Nettverksstandard

IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z

10G støtte

Ja

Ethernet-kobberkabelteknologi

10BASE-T, 100BASE-T, 1000BASE-T, 1000BASE-X

Portspeiling

Ja

IP-ruting

Ja

Policy-basert routing

Ja

Strømningskontroll støtte

Ja

Linkaggregasjon/Linksamling

Ja

Auto MDI/MDI-X

Ja

Treprotokoll (spekter)

Ja

Ethernet LAN dataoverføringshastigheter

10,100,1000 Mbit/s

MAC-adresse automatisk læring støttes

Ja

Ethernet Ring Protection Switching (ERPS)

Ja

Address Resolution Protocol (ARP)-oppføringer (maks.)

4096

Neighbor Discovery Protocol (ND)-oppføringer

3000

VLAN støtte

Ja

Virtuelle LAN-funksjoner

MVRP, Port-based VLAN, Private VLAN, Tagged VLAN, Voice VLAN

Antall VLAN

1020

Ruting/svitsjekapasitet

52 Gbit/s

Gjennomstrømming

77 Mpps

Størrelse på adressetabell

32000 oppføringer

Lagre-og-videresend

Ja

Statisk ruting

Ja

Jumbo Frames-støtte

Ja

Jumbo rammer

9216

DHCP-funksjoner

DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 snooping

Access Control List (ACL)/tilgangskontrolliste

Ja

IGMP-snooping

Ja

Sikkerhetsalgoritmer

802.1x RADIUS, EAP, HTTPS, MD5, PEAP, SNMP, SNMPv2, SNMPv3, SSH-2, TLS, TTLS

Autentisering

MAC-basert autentisering

Passordbeskyttelse

Ja

Persistent MAC Learning (Sticky MAC)

Ja

Autentiseringstype

AAA, IEEE 802.1x, RADIUS, TACACS+

Køplanleggingsalgoritmer

SP (programvare), Weighted random early detection (WRED)

Multicast-støtte

Ja

IPv4 Multicast-oppføringer

3200

IPv6 Multicast-oppføringer

1650

Multicast Listener Discovery (MLD)-snooping

Yes

Virtual Router Redundancy Protocol (VRRP)

Ja

Routerprotokoll

BGP, IS-IS, OSPF, OSPFv3, RIP-1, RIP-2, RIPng

IP Source Guard (IPSG)

Ja

Rack-montering

Ja

Formfaktor

1U

Produktfarge

Grå

Temperatursensor

Ja

Tilbakestillingsknapp

Ja

LED-indikatorer

Ja

Minnetype

DRAM

Internminne

4000 MB

sFlow

Ja

Liste over RFC-er

RFC 783 TFTP RFC 791 IP RFC 792 ICMP RFC 793 TCP RFC 826 ARP RFC 854 Telnet client and server RFC 894 IP over Ethernet RFC 903 RARP RFC 906 TFTP Bootstrap RFC 951, 1542 BootP RFC 1027 Proxy ARP RFC 1058 RIP v1 RFC 1112 IGMP v1 RFC 1122 Host Requirements RFC 1195 Use of OSI IS-IS for Routing in TCP/IP and Dual Environments (TCP/IP transport only) RFC 1256 IPv4 ICMP Router Discovery (IRDP) RFC 1492 TACACS+RFC 1519 CIDR RFC 1587 OSPF NSSA Option RFC 1591 DNS RFC 1812 Requirements for IPv4 Routers RFC 1981 Path MTU Discovery for IPv6 RFC 2030 SNTP, Simple Network Time Protocol RFC 2068 HTTP server RFC 2080 RIPng for IPv6 RFC 2131 BOOTP/DHCP relay agent and DHCP server RFC 2138 RADIUS Authentication RFC 2139 RADIUS Accounting RFC 2154 OSPF w/Digital Signatures (password, MD-5) RFC 2236 IGMP v2 RFC 2267 Network Ingress Filtering RFC 2328 OSPF v2 (edge-mode) RFC 2338 VRRP RFC 2362 PIM-SM (edge-mode) RFC 2370 OSPF Opaque LSA Option RFC 2453 RIP v2 RFC 2460 Internet Protocol, Version 6 (IPv6) Specification RFC 2461 Neighbor Discovery for IP Version 6 (IPv6) RFC 2463 Internet Control Message Protocol (ICMPv6) for the Internet Protocol Version 6 (IPv6) Specification RFC 2464 Transmission of IPv6 Packets over Ethernet Networks RFC 2474 DiffServ Precedence, including 12 queues/port RFC 2475 DiffServ Core and Edge Router Functions RFC 2526 Reserved IPv6 Subnet Anycast Addresses RFC 2597 DiffServ Assured Forwarding (AF) RFC 2598 DiffServ Expedited Forwarding (EF) RFC 2740 OSPF for IPv6 RFC 2925 MIB for Remote Ping, Trace RFC 3176 sFlow RFC 3376 IGMP v3 RFC 3484 Default Address Selection for Internet Protocol Version 6 (IPv6) RFC 3513 Internet Protocol Version 6 (IPv6) Addressing Architecture RFC 3569 draft-ietf-ssm-arch-06.txt PIM-SSM PIM Source Specific Multicast RFC 3579 RADIUS EAP support for 802.1x RFC 6614 RadSec RFC 3618 Multicast Source Discovery Protocol (MSDP) RFC 3623 OSPF Graceful Restart RFC 4213 Basic Transition Mechanisms for IPv6 Hosts and Routers RFC 4291 IPv6 Addressing Architecture RFC 4443 ICMPv6 for the IPv6 Specification RFC 4541 IBMP and MLD snooping services RFC 4552 OSPFv3 Authentication RFC 4861 Neighbor Discovery for IPv6 RFC 4862 IPv6 Stateless Address Autoconfiguration RFC 4915 MT-OSPF RFC 5095 Deprecation of Type 0 Routing Headers RFC 5176 Dynamic Authorization Extensions to RADIUS RFC 5798 VRRPv3 for IPv6 Draft-ietf-bfd-base-05.txt Bidirectional Forwarding Detection Draft-ietf-idr-restart-10.txt Graceful Restart Mechanism Draft-ietf-isis-restart-02 Restart Signaling for IS-IS Draft-ietf-isis-wg-multi-topology-11 Multi Topology (MT) Routing in IS-IS for BGP Internet draft-ietf-isis-ipv6-06.txt, Routing IPv6 with IS-IS LLDP Media Endpoint Discovery (LLDP-MED), ANSI/ TIA-1057, draft 08 PIM-DM Draft IETF PIM Dense Mode draft-ietf-idmrpimdm-05.txt, draft-ietf-pim-dm-new-v2-04.txt

Vifteløs

Ja

Strømkilde

AC

AC-inngangsspenning

100 - 240 V

AC-inngangsfrekvens

50/60 Hz

Innput-strøm

3 A

Strømforbruk (maks.)

34 W

Strøm over Ethernet (PoE)

Ja

Power over Ethernet (PoE) støttes

PoE+

Antall Power over Ethernet plus (PoE+)-ports

12

Power over Ethernet (PoE) effekt per port

30 W

Total Power over Ethernet (PoE)-budsjett

240 W

Total lagringskapasitet

8 GB

Driftstemperatur (T-T)

0 - 50 °C

Oppbevaringstemperaturomåde (Celsius)

-40 - 70 °C

Relativ luftfuktighet under drift (H-H)

5 - 90%

Lagringsrelativ fuktighet

5 - 95%

Driftshøyde

0 - 3048 m

Bredde

264 mm

Dybde

253,7 mm

Høyde

43,4 mm

Vekt

3,12 kg

Samsvarssertifikat

BSMI, Elektromagnetisk kompatibilitet (EMC), Federal Communications Commission (FCC), RoHS, UL, VCCI
