Prosessorprodusent

Intel

Prosessorfamilie

Intel® Xeon® Silver

Prosessormodell

4514Y

Prosessorfrekvens

2 GHz

Boostfrekvens prosessor

3,4 GHz

Prosessorkjerner

16

Processor cache

30 MB

Antall installerte prosessorer

1

Cachetype prosessor

L3

Internminne

128 GB

Internminnetype

DDR5-SDRAM

Minnespor

16x DIMM

Minneklokke-hastighet

5600 MHz

Minnefordeling

4 x 32 GB

Maksimalt internminne

4 TB

Maksimal lagringskapasitet

153,6 TB

SSD drivergrensesnitt

PCI Express 4.0

RAID-støtte

Ja

Støttede RAI- kontrollere

HPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device

Optisk stasjonstype

Nei

LAN-kontroller

Broadcom BCM57416

Ethernet/bredbåndsforbindelse

Ja

Ethernet-grensesnittype

10 Gigabit Ethernet

Antall ethernets-/bredbåndstilkoblinger (RJ-45)

2

Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter

3

Utvidelsesspor

2-slots (x16 FH, x16 HH) as standard. Upgradeable to 3rd slot in HH (or remove Slot 2 bracket to be FH at Slot 3) in a 2nd processor configuration. And maximum 2 OCP 3.0 PCIe5 slots.

Antall VGA (D-Sub)-porter

1

Chassis-type

Rack (1U)

Administrasjonsfunksjoner

Included - HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download). Optional - HPE iLO Advanced, HPE OneView Advanced and HPE Compute Ops Management Refer to the iLO 6 User Guide

Trusted Platform Module (TPM)

Ja

Trusted Platform Module (TPM)-versjon

2.0

Type strømforsyning

2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit

Redundant strømforsyning

Ja

Krav til strømforsyning

1000 W

Antall overflødige strømforsyninger installert

1

Antall hovedstrømforsyninger

2

Bredde

753,1 mm

Dybde

434,6 mm

Høyde

42,9 mm

Standardvifter

7x High Performance Fans

Harddisktype

None ship standard, 8 SFF supported

Fysisk sikkerhet

UEFI Secure Boot and Secure Start support. Intel Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. Optional Trusted Supply Chain, iLO Security modes, TPM, Chassis Intrusion detection and Bezel Locking kits. For full security features refer to the QuickSpecs.

Antall prosessorer som støttes

1
