Svitsjtype

Håndtert

Ruting/svitsjekapasitet

1920 Gbit/s

Gjennomstrømming

1142,8 Mpps

Forsinkelse (1 Gbps)

2,9 µs

Forsinkelse (10 Gbps)

2 µs

Produktfarge

Grå

Innebygd prosessor

Ja

Prosessormodell

QorIQ P2020

Prosessorfrekvens

1200 MHz

Minnetype

DDR3-SDRAM

Internminne

4096 MB

Flash-minne

16 MB

Strømforsyning medfølger

Nei

AC-inngangsspenning

200 - 240 V

Strømforsyningsnotifikasjon

4 power supply slots 2 minimum power supplies required (ordered separately)

Strøm over Ethernet (PoE)

Nei

Latens

1000 Mb Latency: < 2.8 μs; 10 Gbps Latency: < 1.8 μs; 40 Gbps Latency: < 1.5 μs

Minne og prosessor

Depend on the model: Dual Arm Cortex A9 at 1 GHz; Packet buffer size: 13.5 MB internal Arm 11 at 450 MHz; Packet buffer size: 18 MB internal. Dual Arm Cortex A9 at 1; Packet buffer size: 13.5 MB internal Arm 11 at 550 MHz; Packet buffer size: 18 MB internal. Dual Arm Cortex A9 at 1 GHz; Packet buffer size: 13.5 MB internal Freescale P2020 dual core at 1.2 GHz, 16 MB flash, 1 GB SD Card, 4 GB DDR3 SODIMM.

I/O-porter

12 open module slots Supports a maximum of 288 autosensing 10/100/1000 ports or 288 SFP ports or 96 SFP+ ports or 96 HPE Smart Rate Multi-Gigabit or 24 40 GbE ports, or a combination.

Administrasjonsfunksjoner

HPE Aruba Networking Management Software HPE Aruba Networking Central HPE Intelligent Management Center Basic Software Platform (IMC) Command-line interface Web browser Configuration menu Out-of-band management (RJ-45 Ethernet) Out-of-band management (serial RS-232C or micro USB) SNMP manager

Vekt (imperial)

17,3 kg (38.1 Ibs)

Dimensjoner (B x D x H) (imperisk)

444,5 x 450,9 x 307,3 mm (17.5 x 17.8 x 12.1")

Varmespredning

4900 BTU/t

Bredde

444,5 mm

Dybde

450,9 mm

Høyde

307,3 mm

Vekt

17,3 kg
