Name: Digitus DK-1843-050
SKU: 24104517
Price: 502 NOK
Availability: InStock

Digitus DK-1843-050 | SKU: DK-1843-050 | Brand: Digitus | EAN: 4016032499268<br>

color

Egenskaper

Produktfarge

Kabellengde

Kabelstandard

Kabelskjerming

This is the first connector in the device.

Tilkobling 1

This is the second connector in the device.

Tilkobling 2

The gender of the first connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the part bearing one or which fits into another being called male.

Connector 1 kjønn

The gender of the second connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the indented one or the one fitting around the other being called female.

Connector 2 kjønn

The physical shape or orientation of the first connector, such as whether it is angled, foldable, or rectangular.

Tilkobling 1 formfaktor

The physical shape or orientation of the second connector, such as whether it is angled, foldable, or rectangular.

Tilkobling 2 formfaktor

What the connector contacts are covered with (layer on top).

Kontaktplettering

Indicates whether the connector is equipped with a conductive layer to protect the signal from electromagnetic interference.

Connector-skjerming

The material used to construct the protective outer casing of the connector to reduce electromagnetic interference (e.g. Aluminium).

Connector skjermingsmateriale

The primary material used for the outer protective layer of the product (e.g. Aluminum, Cotton, or ABS synthetics).

Jakkemateriale

The physical cross-sectional profile of the conductor housing, such as flat or round.

Kabelform

The material used for the internal electrical or optical conductors, such as copper, aluminium, or active optical fiber.

Ledermateriale

The configuration of the twisted pair wiring, specifying the number of pairs and wires per pair (e.g. 4x2).

Type parkobling (vridd)

The diameter of the conductor based on the American Wire Gauge standard (e.g. 12).

AWG-ledningsstørrelse

The rate at which a signal or operation repeats, measured in MHz.

Frekvens

The smallest allowable curve the cable can be bent to without risking damage to the internal conductors, measured in millimetres.

Bøyeradius (min)

Indicates whether this product supports is "plug and play". Plug and play is  hardware or software that

Plugg inn og spill

Country where the device is made. Aka Country of manufacture (COM).

Opprinnelsesland

Miljømessige forhold

The minimum and maximum temperatures at which the product can be safely operated.

Driftstemperatur (T-T)

Sertifikater

Specifies the official standards, safety approvals, or regulatory certifications the product has received.

Sertifisering

Vekt og dimensjoner

The distance across the widest part of the circular cross-section of the product, measured in mm.

Ytre diameter

Emballasjeinnhold

The number of individual units contained within a single sales package, measured in pc(s).

Antall per pakke

Datainnpakking

The distance from one side of the packaging to the other.

Pakkebredde

The distance from the front to the back of the packaging.

Pakkedybde

The distance from the top to the bottom of the packaging.

Pakkehøyde

Pakkevekt

Tekniske detaljer

The method used to protect the internal conductors from electromagnetic interference, such as braiding or a combination of foil and braiding.

Skjermingstype

Logistikk data

The specific alphanumeric code used for the classification of goods when importing or exporting through the United Kingdom.

Digitus DK-1843-050

502 kr

502 kr

Produktbeskrivelse

Digitus DK-1843-050

502 kr

502 kr

Egenskaper
Produktfarge	Svart
Kabellengde	5 m
Kabelstandard	Cat8.1
Kabelskjerming	S/FTP (S-STP)
Tilkobling 1	RJ-45
Tilkobling 2	RJ-45
Connector 1 kjønn	Hankjønn
Connector 2 kjønn	Hankjønn
Tilkobling 1 formfaktor	Rett
Tilkobling 2 formfaktor	Rett
Kontaktplettering	Gull
Connector-skjerming	Ja
Connector skjermingsmateriale	Metallfolie
Jakkemateriale	Low smoke zero halogen (LSZH)
Kabelform	Rund
Ledermateriale	Kopper
Type parkobling (vridd)	4x2
AWG-ledningsstørrelse	24/7
Frekvens	2000 MHz
Bøyeradius (min)	1,5 cm
Plugg inn og spill	Ja
Opprinnelsesland	China

Miljømessige forhold
Driftstemperatur (T-T)	-20 - 60 °C

Sertifikater
Sertifisering	IEC 60332-1 IEC 61034 SO/IEC 11801-1; EN-50173; ANSI/TIA 568-C; EN 60603-7-5

Vekt og dimensjoner
Ytre diameter	8 mm

Emballasjeinnhold
Antall per pakke	1 stykker

Datainnpakking
Pakkebredde	340 mm
Pakkedybde	370 mm
Pakkehøyde	10 mm
Pakkevekt	235 g

Tekniske detaljer
Skjermingstype	Foil + braiding

Logistikk data
UK Trade Tariff-kode	85444210
