Prosessorprodusent

AMD

Prosessorstøpsel

Sokkel AM5

Kompatible prosessorserier

AMD Ryzen™ 7

Støttede minnetyper

DDR5-SDRAM

Antall minnespor

4

Minnesportype

DIMM

Minnekanaler

Tokanals

ECC-kompatibilitet

ECC & ikke-ECC

Støttede minneklokkehastigheter

4800,5000,5200,5400,5600,5800,6000,6200,6400 MHz

Maksimalt internminne

128 GB

Ubufret minne

Ja

Støttet lagrings drive type

HDD & SSD

Støttede lagringsgrensesnitt

M.2, PCI Express 4.0, PCI Express 5.0, SATA

Antall støttede HDDer

4

Antall lagringsdrivere som støttes

2

RAID-støtte

Ja

RAID-nivåer

0, 1, 10

USB 2.0-tilkoblinger

2

USB 3.2 Gen 1 (3.1 Gen 1)-kontakter

2

Antall SATA-tilkoblinger

4

Totalt antall SATA-kontakter

4

S/PDIF ut-tilkobling

Ja

Lyd kobling

Ja

Frontpanelkontakt

Ja

ATX strømtilkobling (24-pin)

Ja

Antall viftetilkoblinger

Ja

CPU viftetilkobling

Ja

Antall understellsviftetilkoblinger

3

Perifere (Molex) strømkontakter (4-pin)

4

EPS strømtilkobling (8-pin)

Ja

Antall COM-tilkoblinger

1

TPM-tilkobling

Ja

12V strømkontakt

Ja

RGB LED pin header

Ja

Antall USB 2.0-porter

4

Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter

2

Antall USB 3.2 Gen 2 (3.1 Gen 2) Type-A-porter

2

Antall ethernets-/bredbåndstilkoblinger (RJ-45)

1

Antall VGA (D-Sub)-porter

1

Antall HDMI-porter

1

Antall DisplayPorts

1

Hodetelefonutganger

1

Line-in

Ja

Mikrofon, linje-inn-støpsel

Ja

USB-kontakttype

USB Type-A

Ethernet/bredbåndsforbindelse

Ja

Ethernet-grensesnittype

2.5 Gigabit Ethernet

Wi-Fi

Ja

Beste Wi-Fi-standard

Wi-Fi 6 (802.11ax)

Wi-Fi-standarder

802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)

Bluetooth

Ja

Bluetooth-versjon

5.2

Systemkort kretsoppsett

AMD B650

Lyd-utgang kanaler

7.1 kanaler

Komponent for

PC

Hovedkort formfaktor

Micro ATX

Hovedkort-chipsettfamilie

AMD

Strømkildetype

ATX

Støttede Windows operativsystemer

Windows 10, Windows 11

PCI Express x16 (Gen 4.x)-spor

3

BIOS-type

UEFI AMI

BIOS minnestørrelse

256 Mbit

Clear CMOS-knapp

Ja

Bredde

244 mm

Dybde

244 mm

Kabler inkludert

SATA

Forhåndsinstallert programvare

ASUS Exclusive Software Armoury Crate - Aura Creator - Aura Sync - Fan Xpert 2+ - Power Saving AI Suite 3 - TurboV EVO - DIGI+ VRM - PC Cleaner ASUS CPU-Z MyASUS Norton Anti-virus software (Free Trial version) WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode

Lydutgang

Realtek 7.1 Surround Sound High Definition Audio CODEC*
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
Audio Features
- Audio Shielding
- Premium audio capacitors
- Dedicated audio PCB layers
* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.

Spesielle funksjoner

Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports*
AMD Ryzen^™ 7000 Series Desktop Processors
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
AMD B650 Chipset
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
4 x SATA 6Gb/s ports
* AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/10 and SATA RAID 0/1/10.

Grafikkutgang

1 x DisplayPort**
1 x VGA port
1 x HDMI^® port***
* Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications.
** Supports max. 8K@60Hz as specified in DisplayPort 1.4.
*** Supports 4K@60Hz as specified in HDMI^® 2.1.
