Ethernet WAN

Ja

DSL WAN

Nei

SIM-kortspor

Nei

3G / 4G USB-modem kompatibilitet

Nei

Nettverksstandard

IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11s, IEEE 802.11v, IEEE 802.3, IEEE 802.3az, IEEE 802.3u

Ethernet/bredbåndsforbindelse

Ja

Ethernet LAN dataoverføringshastigheter

10,100 Mbit/s

Full tosidig

Ja

Auto MDI/MDI-X

Ja

Webbasert administrasjon

Ja

Quality of Service (QoS) støtte

Ja

Tilbakestillingsknapp

Ja

Antall ethernets-/bredbåndstilkoblinger (RJ-45)

2

DHCP-klient

Ja

DHCP-server

Ja

Sikkerhetsalgoritmer

AES-CCMP, EAP-TLS, OWE, TKIP, WPA-EAP, WPA-PSK, WPA2-Enterprise-PEAP, WPA2-PSK, WPA3-EAP, WPA3-SAE

Access Control List (ACL)/tilgangskontrolliste

Ja

VPN-støtte

OpenVPN Multiple clients and a server can run simultaneously, 27 encryption methods OpenVPN Encryption DES-CBC 64, RC2-CBC 128, DES-EDE-CBC 128, DES-EDE3-CBC 192, DESX-CBC 192, BF-CBC 128, RC2-40-CBC 40, CAST5-CBC 128, RC2-64-CBC 64, AES-128-CBC 128, AES-128-CFB 128, AES-128-CFB1 128, AES-128-CFB8 128, AES-128-OFB 128, AES-128-GCM 128, AES-192-CFB 192, AES-192-CFB1 192, AES-192-CFB8 192, AES-192-OFB 192, AES-192-CBC 192, AES-192-GCM 192, AES-256-GCM 256, AES-256-CFB 256, AES-256-CFB1 256, AES-256-CFB8 256, AES-256-OFB 256, AES-256-CBC 256 IPsec IKEv1, IKEv2, with 14 encryption methods for IPsec (3DES, DES, AES128, AES192, AES256, AES128GCM8, AES192GCM8, AES256GCM8, AES128GCM12, AES192GCM12, AES256GCM12, AES128GCM16, AES192GCM16, AES256GCM16) GRE GRE tunnel, GRE tunnel over IPsec support PPTP, L2TP Client/Server instances can run simultaneously, L2TPv3, L2TP over IPsec support Stunnel Proxy designed to add TLS encryption functionality to existing clients and servers without any changes in the program’s code DMVPN Method of building scalable IPsec VPNs SSTP SSTP client instance support ZeroTier ZeroTier VPN client support WireGuard WireGuard VPN client and server support Tinc Tinc offers encryption, authentication and compression in it's tunnels. Client and server support.

Innebygd prosessor

Ja

Prosessorprodusent

MediaTek

Prosessorarkitektur

MIPS 24Kc

Prosessorfrekvens

580 MHz

Flash-minne

16 MB

Internminne

128 MB

Internminnetype

DDR2

Produktfarge

Svart

Kroppsmateriale

Aluminium

Kan monteres på vegg

Ja

LED-indikatorer

LAN, Kraft indikator, WAN

Antennetilkoblingstype

RP-SMA

Strømkildetype

DC

Driftstemperatur (T-T)

-40 - 70 °C

Relativ luftfuktighet under drift (H-H)

10 - 90%

Bredde

113,1 mm

Dybde

68,6 mm

Høyde

25 mm

Vekt

142,3 g

Montering

DIN-rail
