Inngangsspenning

230 V

Bryteevne

25 A

Internasjonal beskyttelses (IP)-kode

IP20

Intallasjonstype

DIN-skinne

Produktfarge

Flerfarget

Vekt

224 g

Pakkebredde

94 mm

Pakkedybde

22 mm

Pakkehøyde

80 mm

Pakkevekt

236 g

Samsvarssertifikat

CE, RoHS

Number of conductors (without earthing)

1

Remote signalling contact

Ja

Integrated backup fuse

Nei

Integrated short-circuit protection

Nei

Maximum conductor cross section solid (solid, stranded)

25

Mounting method

DIN rail mounted

Batteri inkludert

Nei

Signalling at the device

Optical

Maximum discharge surge current (8/20)

40 A

Maximum continuous voltage (AC)

350 V

Maximum conductor cross section flexible (fine-strand)

16

Nominal discharge surge current (8/20)

40 A

Maximum overcurrent protection device, series connection (fuse)

63 A

Maximum overcurrent protection device, parallel connection (fuse)

315 A

Voltage protection level L-N

1,4 kV

Voltage protection level N-Pe

1,5 kV

Minimum ordreantall

1 stykker
