Name: Siemens 3SU1802-0NE00-4SB1, 504 g, 172 mm, 95 mm, 129 mm
Brand: Siemens
SKU: 10411930
Price: 1863 NOK
Availability: InStock

Siemens 3SU1802-0NE00-4SB1, 504 g, 172 mm, 95 mm, 129 mm | SKU: 3SU18020NE004SB1 | Brand: Siemens | EAN: 4047621072616<br>

Tekniske detaljer

The colour e.g. red, blue, green, black, white.

Produktfarge

What the casing of the product is made of.

Kroppsmateriale

The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".

Internasjonal beskyttelses (IP)-kode

Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.

Samsvarssertifikat

The total quantity of push buttons supplied with the product, measured in pc(s).

Antall trykknapper som medfølger

The standard rating that defines the level of protection provided by the enclosure against environmental hazards such as dust, water, and corrosion.

Beskyttelsesgrad (NEMA)

The total quantity of normally open (NO) auxiliary contacts available for signaling or interlocking purposes.

Antall normalt åpne kontakter

The total number of normally closed contacts available for signaling or interlocking purposes.

Antall normalt lukkede kontakter

The specified direct current voltage required to power the control circuit of the device.

Nominell styreforsyningsspenning (DC)

The total number of individual switches or control points available on the unit.

Antall kommandoposisjoner

The total quantity of mushroom-shaped push buttons integrated into the unit.

Antall soppformede trykknapper

The specified alternating current voltage required to power the control circuit at a frequency of 50Hz.

Nominell styreforsyningsspenning (AC 50 Hz)

The specified voltage required for the control circuit to operate correctly at a frequency of 60 Hz.

Nominell styreforsyningsspenning (AC 60 Hz)

Indicates whether the product is designed to house or function as part of an emergency stop system.

Egnet for nødstopp

The smallest number of units that can be purchased in a single order, measured in pc(s).

Minimum ordreantall

Indicates whether the product is supplied with a battery.

Batteri inkludert

The highest number of units that can be purchased in a single order, measured in pc(s).

Siemens 3SU1802-0NE00-4SB1, 504 g, 172 mm, 95 mm, 129 mm

1 863 kr

1 863 kr

Produktbeskrivelse

Siemens 3SU1802-0NE00-4SB1, 504 g, 172 mm, 95 mm, 129 mm

1 863 kr

1 863 kr

Tekniske detaljer
Produktfarge	Grå
Kroppsmateriale	Plast
Internasjonal beskyttelses (IP)-kode	IP67, IP69K
Samsvarssertifikat	CE, RoHS, REACH
Antall trykknapper som medfølger	1 stykker
Beskyttelsesgrad (NEMA)	1
Antall normalt åpne kontakter	1
Antall normalt lukkede kontakter	2
Nominell styreforsyningsspenning (DC)	5 - 500 V
Antall kommandoposisjoner	2
Antall soppformede trykknapper	1
Nominell styreforsyningsspenning (AC 50 Hz)	5 - 500 V
Nominell styreforsyningsspenning (AC 60 Hz)	5 - 500 V
Egnet for nødstopp	Ja
Minimum ordreantall	1 stykker
Batteri inkludert	Nei
Maksimalt bestillingsantall	1 stykker

Vekt og dimensjoner
Pakkevekt	504 g
Pakkedybde	172 mm
Pakkebredde	95 mm
Pakkehøyde	129 mm
