Name: MEAN WELL SDR-480P-48 strømforsyning for DIN-skinne 48 V/DC 10 A 480 W 1 utgang
SKU: 3540463
Price: 2034 NOK
Availability: InStock

MEAN WELL SDR-480P-48 strømforsyning for DIN-skinne 48 V/DC 10 A 480 W 1 utgang | SKU: SDR-480P-48 | Brand: Mean Well | EAN: 4711287422435<br>

color

weight

Energihåndtering

The total power that is needed by the device

Total strøm

This is the maximum power required by the device or peak music power.

Toppeffekt

The voltage of the AC electricity that is inputted into the product.

AC-inngangsspenning

AC-inngangsfrekvens

Strømfaktor

Power Factor Correction (PFC) type

Holdtid

Effektivitet

Ytelse

Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism.

Gjennomsnittstid mellom feil (MTBF)

Design

Produktfarge

Miljømessige forhold

The minimum and maximum temperatures at which the product can be safely operated.

Driftstemperatur (T-T)

The minimum and maximum temperatures at which the product can be safely stored.

Oppbevaringstemperaturomåde (Celsius)

Relativ luftfuktighet under drift (H-H)

Safety regulation & standards

List of regulatory safety standards for all countries in which this product has been certified.

Sikkerhet

Vekt og dimensjoner

The measurement or extent of something from side to side.

Bredde

The distance from the front to the back of something.

Dybde

The measurement of the product from head to foot or from base to top.

Høyde

Weight of the product without packaging (net weight). If possible

MEAN WELL SDR-480P-48 strømforsyning for DIN-skinne 48 V/DC 10 A 480 W 1 utgang

2 034 kr

2 034 kr

Produktbeskrivelse

MEAN WELL SDR-480P-48 strømforsyning for DIN-skinne 48 V/DC 10 A 480 W 1 utgang

2 034 kr

2 034 kr

Energihåndtering
Total strøm	480 W
Toppeffekt	720 W
AC-inngangsspenning	90 - 264 V
AC-inngangsfrekvens	47 - 63 Hz
Strømfaktor	0,94
Power Factor Correction (PFC) type	Aktiv
Holdtid	14 ms
Effektivitet	94%

Ytelse
Gjennomsnittstid mellom feil (MTBF)	112900 timer

Design
Produktfarge	Metallisk

Miljømessige forhold
Driftstemperatur (T-T)	-25 - 70 °C
Oppbevaringstemperaturomåde (Celsius)	-40 - 85 °C
Relativ luftfuktighet under drift (H-H)	20 - 90%

Safety regulation & standards
Sikkerhet	UL508, TUV EN60950-1

Vekt og dimensjoner
Bredde	85,5 mm
Dybde	128,5 mm
Høyde	125,2 mm
Vekt	1,6 kg

Andre funksjoner
Rensetid	150 ms

MEAN WELL SDR-480P-48 strømforsyning for DIN-skinne 48 V/DC 10 A 480 W 1 utgang

2 034 kr

2 034 kr

Produktbeskrivelse

Spesifikasjoner

MEAN WELL SDR-480P-48 strømforsyning for DIN-skinne 48 V/DC 10 A 480 W 1 utgang

2 034 kr

2 034 kr
