Name: Eaton 9SX3000IR rackmontert UPS 3000 VA 2700 W, 2U
SKU: 4892727
Price: 29290 NOK
Availability: InStock

Eaton 9SX3000IR rackmontert UPS 3000 VA 2700 W, 2U | SKU: 9SX3000IR | Brand: Eaton Corporation | EAN: 0743172091147<br>

color

noise_level

weight

Egenskaper

The two main UPS topologies are Double-Conversion True Online and Standby / Eco. Many quality-based considerations are involved when choosing the the optimal UPS for the job, like how they are coping with voltage disturbances.

UPS topologi

The maximum power that the device can produce.

Output strømkapasitet (VA)

Utgangseffekt

The minumum voltage needed by the device during operation.

Inngangsspenning (min.)

The  maximum input voltage supported by the device.

Inngangsspenning (maks.)

The frequency (Hz) which is required to power the product.

Inngangsfrekvens

The frequency of the electrical current delivered by the device, measured in hertz (e.g. 47/53 Hz).

Utgangsfrekvens

Strøm (maks.)

The amplitude level of the undesired background noise

Støynivå

Tilkoblingsevne

AC-utgangstyper

A power plug is a 2 or 3 pinned device that is placed into an electrical socket in order to make an electrical connection.

Strømuttak

The number of sockets in the device where AC electrical power can be connected.

Antall AC outlets

The device features a socket into which a USB cable can be plugged.

USB-port

Indicates whether the device features a serial port for communication and management purposes.

Serielt grensesnitt

The physical connector standard used for the serial communication port (e.g. DB9 or RJ-45).

Seriell grensesnittype

The number of sockets (ports) for RS-232. An RS-232 serial port was once a standard feature of a personal computer

RS-232-port

Design

Formfaktor

Rack-kapasitet

Produktfarge

Skjermtype

Miljømessige forhold

The minimum and maximum temperatures at which the product can be safely operated.

Driftstemperatur (T-T)

Sertifikater

Specifies the official standards, safety approvals, or regulatory certifications the product has received.

Sertifisering

Safety regulation & standards

List of regulatory safety standards for all countries in which this product has been certified.

Eaton 9SX3000IR rackmontert UPS 3000 VA 2700 W, 2U

29 290 kr

29 290 kr

Produktbeskrivelse

Eaton 9SX3000IR rackmontert UPS 3000 VA 2700 W, 2U

29 290 kr

29 290 kr

Egenskaper
UPS topologi	Dobbeltkonvertering (Online)
Output strømkapasitet (VA)	3 kVA
Utgangseffekt	2700 W
Inngangsspenning (min.)	200 V
Inngangsspenning (maks.)	276 V
Inngangsfrekvens	40 - 70 Hz
Utgangsfrekvens	50/60 Hz
Strøm (maks.)	16 A
Støynivå	45 dB

Tilkoblingsevne
AC-utgangstyper	C13 kopling, C19 kopling
Strømuttak	C20 kopling
Antall AC outlets	9 AC-utganger
USB-port	Ja
Serielt grensesnitt	Ja
Seriell grensesnittype	RS-232
RS-232-port	1

Design
Formfaktor	Rackmontering
Rack-kapasitet	2U
Produktfarge	Svart
Skjermtype	LCD

Miljømessige forhold
Driftstemperatur (T-T)	0 - 40 °C

Sertifikater
Sertifisering	IEC/EN 62040 -2 , FCC B, CISPR22 B, CE /CB (TUV) / cULus / EAC / RCM

Safety regulation & standards
Sikkerhet	IEC/EN 62040-1, UL 1778, CSA 22.2

Vekt og dimensjoner
Bredde	438 mm
Dybde	608 mm
Høyde	86,5 mm
Vekt	26,5 kg
