Prosessorprodusent

AMD

Prosessorstøpsel

Sokkel AM5

Kompatible prosessorserier

AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series

Støttede prosessorkontakter

Sokkel AM5

Støttede minnetyper

DDR5-SDRAM

Antall minnespor

2

Minnesportype

DIMM

Minnekanaler

Tokanals

ECC-kompatibilitet

ECC & ikke-ECC

Maksimalt internminne

128 GB

Ubufret minne

Ja

Støttet lagrings drive type

HDD & SSD

Støttede lagringsgrensesnitt

M.2, SATA III

Antall støttede HDDer

4

Antall lagringsdrivere som støttes

9

RAID-støtte

Ja

RAID-nivåer

0, 1, 5, 10

Støtter parallellprosesseringsteknologi

Støttes ikke

On-board grafikkort

Nei

USB 2.0-tilkoblinger

2

USB 3.2 Gen 1 (3.1 Gen 1)-kontakter

2

USB 3.2 Gen 2x2-kontakter

2

Antall SATA III-tilkoblinger

4

Lydtilkobling på fremsiden

Ja

Frontpanelkontakt

Ja

ATX strømtilkobling (24-pin)

Ja

CPU viftetilkobling

Ja

Antall understellsviftetilkoblinger

2

EPS strømtilkobling (8-pin)

Ja

12V strømkontakt

Ja

RGB LED pin header

Ja

Antall RGB LED-pinnehoder

3

Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter

2

Antall USB 3.2 Gen 2 (3.1 Gen 2) Type-A-porter

5

Antall USB 3.2 Gen 2 (3.1 Gen 2)Type-C-porter

1

Antall USB 4 Gen 3x2-porter

2

Antall ethernets-/bredbåndstilkoblinger (RJ-45)

1

Antall PS/2-porter

1

S/PDIF-utport

Ja

WiFi-AP antennestøpsel

1

Ethernet/bredbåndsforbindelse

Ja

Ethernet-grensesnittype

5 Gigabit Ethernet

Wi-Fi

Ja

Beste Wi-Fi-standard

Wi-Fi 7 (802.11be)

Wi-Fi-standarder

Wi-Fi 7 (802.11be)

Bluetooth

Ja

Bluetooth-versjon

5.4

Systemkort kretsoppsett

AMD X870E

Lyd-utgang kanaler

7.1 kanaler

Produktfarge

Svart

Komponent for

PC

Hovedkort formfaktor

ATX

Hovedkort-chipsettfamilie

AMD

Støttede Windows operativsystemer

Windows 11

PCI Express x1 (Gen 3.x) slots

1

PCI Express x4 (Gen 4.x)-spor

1

PCI Express x16 (Gen 4.x)-spor

2

PCI Express x16 (Gen 5.x) spor

2

Antall M.2 (M)-spor

5

1. M.2 største nøkkelstørrelse

2280

1. M.2 høyeste PCI Express-generasjon

5.0

2. M.2 største nøkkelstørrelse

2280

2. M.2 høyeste PCI Express-generasjon

5.0

3. M.2 største nøkkelstørrelse

2280

3. M.2 høyeste PCI Express-generasjon

5.0

4. M.2 største nøkkelstørrelse

22110

4. M.2 høyeste PCI Express-generasjon

4.0

5. M.2 største nøkkelstørrelse

22110

5. M.2 høyeste PCI Express-generasjon

4.0

BIOS-type

UEFI AMI

BIOS minnestørrelse

512 Mbit

Pakkebredde

370 mm

Pakkedybde

312 mm

Pakkehøyde

108 mm

Pakkevekt

4,16 kg

Bredde

305 mm

Dybde

244 mm

Kabler inkludert

SATA

Antenne inkludert

Ja

Skruer inkludert

Ja

Drivere medfølger

Ja

Lydutgang

"ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080*
- Impedance sense for front and rear headphone outputs
- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
- High quality 120 dB SNR stereo playback output and 110 dB SNR recording input
- Supports up to 32-Bit/384 kHz playback on front panel"
Audio Features
- SupremeFX Shielding Technology
- Savitech SV3H712 AMP
- Gold-plated audio jacks
- Rear optical S/PDIF out port
- Premium audio capacitors
- Audio cover
* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
** The LINE OUT port on the rear panel does not support spatial audio. If you wish to use spatial audio, make sure to connect your audio output device to the audio jack on the front panel of your chassis or use a USB interface audio device.

Spesielle funksjoner

Supports 5 x M.2 slots and 4 x SATA 6Gb/s ports*
AMD Ryzen™ 9000 & 7000 Series Desktop Processors
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)**
M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)**
AMD Ryzen™ 8000 Series Desktop Processors
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
M.2_2 slot (Key M), type 2242/2260/2280 (Not supports)
M.2_3 slot (Key M), type 2242/2260/2280 (Not supports)
AMD X870E Chipset
DIMM.2_1 slot (Key M), type 2230/2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
DIMM.2_2 slot (Key M), type 2230/2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
4 x SATA 6Gb/s ports
* Specifications vary by CPU types.
**When M.2_2 is enabled, but M.2_3 is not in use, PCIEX16_1 will run in x8 mode and PCIEX16_2 will be disabled.
**When M.2_3 is enabled, but M.2_2 is not in use, PCIEX16_1 will run in x8 mode and PCIEX16_2 will run in x4 mode.
**When both M.2_2 and M.2_3 are enabled, PCIEX16_1 will run in x8 mode and PCIEX16_2 will be disabled.

Andre egenskaper

2 x DIMM slots, max. 128GB, DDR5
Supports up to
8200+MT/s(OC) with Ryzen™ 9000 Series Processors,
9600+MT/s(OC) with Ryzen™ 8000 Series Processors
8000+MT/s(OC) with Ryzen™ 7000 Series Processors,
ECC and Non-ECC, Un-buffered Memory*
Dual channel memory architecture
Supports AMD Extended Profiles for Overclocking (EXPO™)
ASUS Enhanced Memory Profile (AEMP)
* Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/download-center/.
* Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.

Grafikkutgang

2 x USB4^® (40Gbps) ports support USB Type-C^® display outputs*
Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications.
VGA resolution support depends on processors' or graphic cards' resolution.
*Supports max. 4K@60Hz as specified in DisplayPort 1.4a
