Prosessorprodusent

AMD

Prosessorstøpsel

Sokkel AM5

Kompatible prosessorserier

AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series

Støttede prosessorkontakter

Sokkel AM5

Støttede minnetyper

DDR5-SDRAM

Antall minnespor

4

Minnesportype

DIMM

Minnekanaler

Tokanals

ECC-kompatibilitet

Ikke-ECC

Maksimalt internminne

256 GB

Ubufret minne

Ja

Støttet lagrings drive type

HDD & SSD

Støttede lagringsgrensesnitt

M.2, SATA III

Antall støttede HDDer

4

Antall lagringsdrivere som støttes

8

RAID-støtte

Ja

RAID-nivåer

0, 1, 10, 5

Støtter parallellprosesseringsteknologi

Støttes ikke

On-board grafikkort

Nei

USB 2.0-tilkoblinger

2

USB 3.2 Gen 1 (3.1 Gen 1)-kontakter

1

USB 3.2 Gen 2x2-kontakter

1

Antall SATA III-tilkoblinger

4

Lydtilkobling på fremsiden

Ja

Frontpanelkontakt

Ja

ATX strømtilkobling (24-pin)

Ja

CPU viftetilkobling

Ja

Antall CPU-viftekontakter

2

Antall understellsviftetilkoblinger

5

Understell inngrepstilkobling

Ja

EPS strømtilkobling (8-pin)

Ja

Antall EPS-strømkontakter (8-pinners)

2

12V strømkontakt

Ja

Antall vannpumpekontakter

1

Antall temperaturfølerhoder

1

RGB LED pin header

Ja

Antall RGB LED-pinnehoder

3

Antall USB 2.0-porter

2

Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter

6

Antall USB 3.2 Gen 2 (3.1 Gen 2) Type-A-porter

3

Antall USB 3.2 Gen 2 (3.1 Gen 2)Type-C-porter

1

Antall USB 4 Gen 3x2-porter

2

Antall ethernets-/bredbåndstilkoblinger (RJ-45)

1

Antall HDMI-porter

1

Mikrofon, linje-inn-støpsel

Ja

S/PDIF-utport

Ja

WiFi-AP antennestøpsel

1

Ethernet/bredbåndsforbindelse

Ja

Ethernet-grensesnittype

5 Gigabit Ethernet

Wi-Fi

Ja

Beste Wi-Fi-standard

Wi-Fi 7 (802.11be)

Wi-Fi-standarder

Wi-Fi 7 (802.11be)

WLAN-kontrollermodell

Realtek RTL8922AE

Bluetooth

Ja

Bluetooth-versjon

5.4

Systemkort kretsoppsett

AMD X870E

Lydbrikke

Realtek ALC1220P

Lyd-utgang kanaler

7.1 kanaler

Produktfarge

Svart

Komponent for

PC

Hovedkort formfaktor

ATX

Hovedkort-chipsettfamilie

AMD

Form for nedkjøling

Passiv

Støttede Windows operativsystemer

Windows 11

PCI Express x16 (Gen 4.x)-spor

1

PCI Express x16 (Gen 5.x) spor

1

Antall M.2 (M)-spor

4

1. M.2 største nøkkelstørrelse

2280

1. M.2 høyeste PCI Express-generasjon

5.0

2. M.2 største nøkkelstørrelse

22110

2. M.2 høyeste PCI Express-generasjon

5.0

3. M.2 største nøkkelstørrelse

2280

3. M.2 høyeste PCI Express-generasjon

4.0

4. M.2 største nøkkelstørrelse

2280

4. M.2 høyeste PCI Express-generasjon

4.0

BIOS-type

UEFI AMI

BIOS minnestørrelse

256 Mbit

Pakkebredde

353 mm

Pakkedybde

273 mm

Pakkehøyde

68 mm

Pakkevekt

2,07 kg

Bredde

305 mm

Dybde

244 mm

Kabler inkludert

SATA

Antenne inkludert

Ja

Lydutgang

Realtek ALC1220P 7.1 Surround Sound
High Definition Audio CODEC*
- Impedance sense for front and rear
headphone outputs
- Internal audio Amplifier to enhance the
highest quality sound for headphone and speakers
- Supports: Jack-detection,
Multi-streaming, Front Panel Jack-retasking
- High quality 120 dB SNR stereo playback
output and 113 dB SNR recording input (Line-in)
- Supports up to 32-Bit/192 kHz
playback*
Audio Features
- SupremeFX Shielding Technology
- Savitech SV3H712 AMP
- Rear optical S/PDIF out port
- Premium audio capacitors
- Audio cover
* The LINE OUT port on the rear panel does
not support spatial audio. If you wish to use spatial audio, make sure to
connect your audio output device to the audio jack on the front panel of your
chassis or use a USB interface audio device.

Spesielle funksjoner

Supports 4 x M.2 slots and 4 x SATA 6Gb/s
ports
AMD Ryzen™ 9000 & 7000 Series Desktop
Processors
M.2_1 slot (Key M), type 2242/2260/2280
(supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2280/22110
(supports PCIe 5.0 x4 mode)*
AMD Ryzen™ 8000 Series Desktop Processors*
M.2_1 slot (Key M), type 2242/2260/2280
(supports PCIe 4.0 x4/x2 mode)
M.2_2 slot (Key M), type 2280/22110 (Not
supports)**
AMD X870E Chipset
M.2_3 slot (Key M), type 2280 (supports
PCIe 4.0 x4 mode)
M.2_4 slot (Key M), type 2280 (supports
PCIe 4.0 x4 mode)
4 x SATA 6Gb/s ports
* M.2_2 shares bandwidth with PCIEX16(G5).
When M.2_2 is occupied with SSD device, PCIEX16(G5) will run x8 only.
** M.2_2 will be disabled when using AMD
Ryzen™ 8000 Series Desktop Processors.

Andre egenskaper

4 x DIMM slots, max. 256GB, DDR5
Supports up to 8000+MT/s(OC) with Ryzen™
9000 & 8000 & 7000 Series Processors
Dual channel memory architecture
Supports AMD Extended Profiles for
Overclocking (EXPO™)
Supports DIMM Fit / DIMM Fit Pro
ASUS Enhanced Memory Profile (AEMP)
* Supported memory types, data rate
(speed), and number of DRAM modules vary depending on the CPU and memory
configuration, for more information please refer to CPU/Memory Support list
under the Support tab of product information site or visit https://www.asus.com/support/download-center/.
Adjustments will be made based on the specifications of mass-produced memory
products available on the market.
** Non-ECC, un-buffered DDR5 memory
supports On-Die ECC function.

Grafikkutgang

1 x HDMI™ port**
2 x USB4^® (40Gbps) ports support USB
Type-C^® display outputs***
* Graphics specifications may vary between
CPU types. Please refer to AMD CPU specifications.
** Supports 4K@60Hz as specified in HDMI
2.1.
*** Supports max. 4K@60Hz as specified in
DisplayPort 1.4a
**** VGA resolution support depends on
processors' or graphic cards' resolution.
