Prosessorprodusent

Intel

Prosessorstøpsel

LGA 1851 (Socket V1)

Kompatible prosessorserier

Intel Core Ultra (Series 2)

Støttede minnetyper

DDR5-SDRAM

Antall minnespor

2

Minnesportype

DIMM

Minnekanaler

Tokanals

ECC-kompatibilitet

Ikke-ECC

Støttet minneklokkehastighet (maks.)

9066 MHz

Maksimalt internminne

128 GB

Ubufret minne

Ja

Støttet lagrings drive type

HDD & SSD

Støttede lagringsgrensesnitt

M.2, SATA III

Antall støttede HDDer

4

Antall lagringsdrivere som støttes

6

RAID-støtte

Ja

RAID-nivåer

0, 1, 5, 10

Støtter parallellprosesseringsteknologi

Støttes ikke

On-board grafikkort

Nei

USB 2.0-tilkoblinger

1

USB 3.2 Gen 1 (3.1 Gen 1)-kontakter

1

USB 3.2 Gen 2 (3.1 Gen 2)-kontakter

1

Antall SATA III-tilkoblinger

4

Lydtilkobling på fremsiden

Ja

ATX strømtilkobling (24-pin)

Ja

CPU viftetilkobling

Ja

Antall CPU-viftekontakter

1

Antall understellsviftetilkoblinger

1

EPS strømtilkobling (8-pin)

Ja

12V strømkontakt

Ja

Antall USB 2.0-porter

2

Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter

3

Antall USB 3.2 Gen 2 (3.1 Gen 2) Type-A-porter

1

Antall USB 3.2 Gen 2x2 Type C-porter

1

Antall ethernets-/bredbåndstilkoblinger (RJ-45)

1

Antall HDMI-porter

1

Antall DisplayPorts

1

Mikrofon, linje-inn-støpsel

Ja

S/PDIF-utport

Ja

Antall Thunderbolt-porter

1

Ethernet/bredbåndsforbindelse

Ja

Ethernet-grensesnittype

2.5 Gigabit Ethernet

Wi-Fi

Ja

Beste Wi-Fi-standard

Wi-Fi 7 (802.11be)

Bluetooth

Ja

Bluetooth-versjon

5.4

Systemkort kretsoppsett

Intel B860

Lydbrikke

Realtek ALC1220P

Lyd-utgang kanaler

7.1 kanaler

Produktfarge

Flerfarget

Komponent for

PC

Hovedkort formfaktor

Mini-ITX

Hovedkort-chipsettfamilie

Intel

Støttede Windows operativsystemer

Windows 11

PCI Express x16 (Gen 5.x) spor

1

Antall M.2 (M)-spor

2

BIOS-type

UEFI AMI

BIOS minnestørrelse

256 Mbit

Clear CMOS-knapp

Ja

Bredde

170 mm

Dybde

170 mm

Lydutgang

Realtek ALC1220P 7.1 Surround Sound High
Definition Audio CODEC*
- Impedance sense for front and rear
headphone outputs
- Internal audio Amplifier to enhance the
highest quality sound for headphone and speakers
- Supports: Jack-detection,
Multi-streaming, Front Panel Jack-retasking
- High quality 120 dB SNR stereo playback
output and 113 dB SNR recording input (Line-in)
- Supports up to 32-Bit/192 kHz
playback*"
Audio Features
- SupremeFX Shielding Technology
- Savitech SV3H712 AMP
- Rear optical S/PDIF out port
- Premium audio capacitors
- Dedicated audio PCB layers
* Due to limitations in HDA bandwidth,
32-Bit/192 kHz is not supported for 7.1 Surround Sound audio.
** A chassis with an HD audio module in the
front panel is required to support 7.1 Surround Sound audio output.

Spesielle funksjoner

Total supports 2 x M.2 slots and 4 x SATA
6Gb/s ports*
Intel^® Core™ Ultra Processors (Series 2)
M.2_1 slot (Key M), type 2260/2280
(supports PCIe 5.0 x4 mode)
Intel^® B860 Chipset**
M.2_2 slot (Key M), type 2242/2260/2280
(supports PCIe 4.0 x4 mode)
4 x SATA 6Gb/s ports
* Intel^® Rapid Storage Technology supports
SATA RAID 0/1/5/10.

Andre egenskaper

2 x DIMM slots, max. 128GB, DDR5
Supports up to 9066+MT/s (OC), Non-ECC
Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)*
Dual channel memory architecture
DIMM Fit
Supports Intel^® Extreme Memory Profile
(XMP) memory module
ASUS Enhanced Memory Profile III (AEMP III)
*Adjustments will be made based on the specifications of mass-produced memory products available on the market.
* Supported memory types, data rate
(speed), and number of DRAM modules vary depending on the CPU and memory
configuration, for more information please refer to CPU/Memory Support list
under the Support tab of product information site or visit
https://www.asus.com/support/download-center/.
* *Non-ECC, un-buffered DDR5 memory
supports On-Die ECC function.

Grafikkutgang

1 x DisplayPort**
1 x HDMI™ port***
1 x Intel^® Thunderbolt™ 4 supports
DisplayPort and Thunderbolt™ video outputs****
* Graphics specifications may vary between
CPU types. Please refer to www.intel.com for any updates.
** Supports max. 4K@60Hz as specified in
DisplayPort 1.4.
*** Supports 4K@60Hz as specified in HDMI
2.1.
****Supports up to 8K@60Hz x1 with DSC,
maximum total bandwidth up to 23.8Gbps, for resolution support please check
DisplayPort 2.1 specs.
***** VGA resolution support depends on
processors' or graphic cards' resolution.
