Prosessorprodusent

AMD

Prosessorstøpsel

Sokkel AM5

Kompatible prosessorserier

AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series

Støttede prosessorkontakter

Sokkel AM5

Støttede minnetyper

DDR5-SDRAM

Antall minnespor

4

Minnesportype

DIMM

Minnekanaler

Tokanals

ECC-kompatibilitet

ECC & ikke-ECC

Støttet minneklokkehastighet (maks.)

8000 MHz

Maksimalt internminne

256 GB

Ubufret minne

Ja

Støttet lagrings drive type

HDD & SSD

Støttede lagringsgrensesnitt

M.2, SATA III

Antall støttede HDDer

2

Antall lagringsdrivere som støttes

6

RAID-støtte

Ja

RAID-nivåer

0, 1, 5, 10

Støtter parallellprosesseringsteknologi

Støttes ikke

On-board grafikkort

Nei

Maksimal oppløsning

7680 x 4320 piksler

USB 2.0-tilkoblinger

2

USB 3.2 Gen 1 (3.1 Gen 1)-kontakter

1

USB 3.2 Gen 2 (3.1 Gen 2)-kontakter

1

Antall SATA III-tilkoblinger

2

Lydtilkobling på fremsiden

Ja

Frontpanelkontakt

Ja

ATX strømtilkobling (24-pin)

Ja

CPU viftetilkobling

Ja

Antall CPU-viftekontakter

2

Antall understellsviftetilkoblinger

4

EPS strømtilkobling (8-pin)

Ja

Antall EPS-strømkontakter (8-pinners)

2

Thunderbolt-headers

1

Antall vannpumpekontakter

1

Antall temperaturfølerhoder

1

RGB LED pin header

Ja

Antall RGB LED-pinnehoder

3

Antall USB 2.0-porter

4

Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter

4

Antall USB 3.2 Gen 2 (3.1 Gen 2) Type-A-porter

2

Antall USB 3.2 Gen 2 (3.1 Gen 2)Type-C-porter

1

Antall USB 3.2 Gen 2x2 Type C-porter

1

Antall ethernets-/bredbåndstilkoblinger (RJ-45)

1

Antall HDMI-porter

1

HDMI-versjon

2.1

Antall DisplayPorts

1

DisplayPort-versjon

1.4

Hodetelefonutganger

1

Line-in

Ja

S/PDIF-utport

Ja

Optisk digital lydutgang

1

WiFi-AP antennestøpsel

2

Ethernet/bredbåndsforbindelse

Ja

Ethernet-grensesnittype

2.5 Gigabit Ethernet

Wi-Fi

Ja

Beste Wi-Fi-standard

Wi-Fi 7 (802.11be)

Wi-Fi-standarder

Wi-Fi 7 (802.11be)

Bluetooth

Ja

Bluetooth-versjon

5.4

Systemkort kretsoppsett

AMD B850

Lydbrikke

Realtek ALC4080

Lyd-utgang kanaler

7.1 kanaler

Produktfarge

Svart

Komponent for

PC

Hovedkort formfaktor

ATX

Hovedkort-chipsettfamilie

AMD

Strømkildetype

ATX

Støttede Windows operativsystemer

Windows 11

PCI Express x16 (Gen 4.x)-spor

1

Antall M.2 (M)-spor

4

1. M.2 største nøkkelstørrelse

2280

1. M.2 høyeste PCI Express-generasjon

5.0

2. M.2 største nøkkelstørrelse

22110

2. M.2 høyeste PCI Express-generasjon

5.0

3. M.2 største nøkkelstørrelse

2280

3. M.2 høyeste PCI Express-generasjon

4.0

4. M.2 største nøkkelstørrelse

2280

4. M.2 høyeste PCI Express-generasjon

4.0

BIOS-type

UEFI AMI

BIOS minnestørrelse

256 Mbit

Clear CMOS-knapp

Ja

Bredde

305 mm

Dybde

244 mm

Lydutgang

ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080*
- Impedance sense for front and rear headphone outputs
- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
- High quality 120 dB SNR stereo playback output and 110 dB SNR recording input
- Supports up to 32-Bit/384 kHz playback on front panel
Audio Features
- SupremeFX Shielding Technology
- Savitech SV3H712 AMP
- Rear optical S/PDIF out port
- Premium audio capacitors
- Audio cover
* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
** The LINE OUT port on the rear panel does not support spatial audio. If you wish to use spatial audio, make sure to connect your audio output device to the audio jack on the front panel of your chassis or use a USB interface audio device.

Spesielle funksjoner

Total supports 4 x M.2 slots and 2 x SATA 6Gb/s ports

AMD Ryzen™ 7000 & 9000 Series Desktop Processors
M.2_1 (Key M), type 2242/2260/2280 (supports PCIe 5.0x4 mode)
M.2_2 (Key M), type 2280/22110 (supports PCIe 5.0 x4 mode)
AMD Ryzen™ 8000 Series Desktop Processors
M.2_1 (Key M), type 2242/2260/2280 (supports PCIe 4.0x4 mode)
M.2_2 (Key M), type 2280/22110 (supports PCIe 4.0 x4/x2 mode)*

AMD B850 Chipset
M.2_3 (Key M), type 2280 (supports PCIe 4.0 x4)**
M.2_4 (Key M), type 2280 (supports PCIe 4.0 x4)
2 x SATA 6Gb/s ports
* Specifications vary by CPU types.
** M.2_3 slot shares bandwidth with PCIEX16(G4). When PCIEX16(G4) slot is operating, M.2_3 will be disabled.

AMD RAIDXpert2 Technology
Ryzen™ 9000 Series Processors: RAID 0/1/5/10
Ryzen™ 8000 Series Processors: RAID 0/1
Ryzen™ 7000 Series Processors: RAID 0/1/10

Andre egenskaper

4 x DIMM slots, max. 256GB, DDR5
Supports up to 8000+MT/s (OC) with Ryzen™ 9000 & 8000 & 7000 Series Processors
ECC and Non-ECC, Un-buffered DIMM
Dual channel memory architecture
Supports AMD Extended Profiles for Overclocking (EXPO™)
ASUS Enhanced Memory Profile (AEMP)
* Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/download-center/.
** Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.

Grafikkutgang

1 x DisplayPort*
1 x HDMI™ port**
- Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications.
* Supports max. 8K@30Hz as specified in DisplayPort 1.4
** Supports 4K@60Hz as specified in HDMI 2.1
*** VGA resolution support depends on processors' or graphic cards' resolution.
