Name: 2 m LSZH singlemode OS2 fiberkabel duplex med E2000/APC
SKU: 20167705
Price: 745 NOK
Availability: InStock

2 m LSZH singlemode OS2 fiberkabel duplex med E2000/APC | SKU: RL1902 | Brand: ACT | EAN: 8716065436358<br>

color

Egenskaper

Kabellengde

The standardised properties of the fiber optic cable.

Fiberoptisk type

This is the first connector in the device.

Tilkobling 1

This is the second connector in the device.

Tilkobling 2

The gender of the first connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the part bearing one or which fits into another being called male.

Connector 1 kjønn

The gender of the second connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the indented one or the one fitting around the other being called female.

Connector 2 kjønn

The specific geometry and finish of the fiber optic connector end-face to minimize signal loss, such as APC or UPC.

Etterbehandlingstype på kontakt

Produktfarge

A full-duplex system allows communication in both directions

Full tosidig

Kjernediameter

Kledningsdiameter

Specifies the type of light propagation path within the core, such as Single-mode for long distances or Multi-mode for shorter reaches.

Fibermodusstruktur

The amount of signal power lost as the signal passes through the device, typically measured in decibels (dB).

Innsettingstap

The ratio of power reflected back toward the source to the power delivered into the unit, typically measured in decibels (dB).

Avkastning tap

The primary material used for the outer protective layer of the product (e.g. Aluminum, Cotton, or ABS synthetics).

Jakkemateriale

Miljømessige forhold

The minimum and maximum temperatures at which the product can be safely operated.

Driftstemperatur (T-T)

Emballasjeinnhold

The number of individual units contained within a single sales package, measured in pc(s).

Antall per pakke

Logistikk data

The standardized numerical method of classifying traded products used by customs authorities around the world to identify goods for tariffs and statistics.

2 m LSZH singlemode OS2 fiberkabel duplex med E2000/APC

745 kr

745 kr

Early Black Friday er i gang: se alle deals

Produktbeskrivelse

2 m LSZH singlemode OS2 fiberkabel duplex med E2000/APC

745 kr

745 kr

Early Black Friday er i gang: se alle deals

Egenskaper
Kabellengde	2 m
Fiberoptisk type	OS1/OS2
Tilkobling 1	2x E-2000 (LSH)
Tilkobling 2	2x E-2000 (LSH)
Connector 1 kjønn	Hankjønn
Connector 2 kjønn	Hankjønn
Etterbehandlingstype på kontakt	APC
Produktfarge	Gult
Full tosidig	Ja
Kjernediameter	9 µm
Kledningsdiameter	125 µm
Fibermodusstruktur	Enkeltmodus
Innsettingstap	0,25 dB
Avkastning tap	65 dB
Jakkemateriale	Low smoke zero halogen (LSZH)

Miljømessige forhold
Driftstemperatur (T-T)	-20 - 60 °C

Emballasjeinnhold
Antall per pakke	1 stykker

Logistikk data
Harmonisert system (HS)-kode	85447000
