Svitsjtype

Håndtert

Strømbryterbelegg

L2/L4

MIB-støtte

RFC 1155 Structure of Management Information (SMI) RFC 1157 SNMPv1 RFC 1212, RFC 1213, RFC 1215 MIB-II, Ethernet-like MIB, and TRAPs RFC 1493 Bridge MIB RFC 1643 Ethernet MIB RFC 1724 RIPv2 MIB RFC 1905 RFC 1907 SNMP v2c, SMIv2 and Revised MIB-II RFC 1981 Path MTU Discovery for IPv6 RFC 2011 SNMPv2 Management Information Base for the IP using SMIv2 RFC 2012 SNMPv2 Management Information Base for the Transmission Control Protocol using SMIv2 RFC 2013 SNMPv2 Management Information Base for the User Datagram Protocol using SMIv2 RFC 2096 IPv4 Forwarding Table MIB RFC 2287 System Application Packages MIB RFC 2460 IPv6 Specification RFC 2464 Transmission of IPv6 Packets over Ethernet Networks RFC 2570-2575 SNMPv3, User-based Security, Encryption, and Authentication RFC 2576 Coexistence between Version 1, Version 2, and Version 3 of the Internet-standard Network Management Framework RFC 2578 SNMP Structure of Management Information MIB RFC 2579 SNMP Textual Conventions for SMIv2 RFC 2665 Definitions of Managed Objects for the Ethernet-like Interface Types RFC 2819 RMON MIB RFC 2863 The Interfaces Group MIB RFC 2922 LLDP MIB RFC 2925 Definitions of Managed Objects for Remote Ping, Traceroute, and Lookup Operations RFC 3413 SNMP Application MIB RFC 3414 User-based Security Model for SNMPv3 RFC 3415 View-based Access Control Model (VACM) for SNMP RFC 3484 Default Address Selection for IPv6 RFC 3621 PoE-MIB (PoE switches only) RFC 3810 Multicast Listener Discovery Version 2 (MLDv2) for IPv6 RFC 4188 STP and Extensions MIB RFC 4213 Basic Transition Mechanisms for IPv6 Hosts and Routers RFC 4291 IPv6 Addressing Architecture RFC 4363 Definitions of Managed Objects for Bridges with Traffic Classes, Multicast Filtering, and VLAN Extensions RFC 4443 ICMPv6 for the IPv6 Specification RFC 4861 Neighbor Discovery for IPv6 RFC 4862 IPv6 Stateless Address Autoconfiguration Draft – blumenthal – aes – usm - 08 Draft – reeder - snmpv3 – usm - 3desede -00

Antall Basic switching RJ-45 Ethernet-ports

48

Basic switching RJ-45 Ethernet ports-type

Gigabit Ethernet (10/100/1000)

Fibre Channel-porter

4

Fiberoptisk kontakt

SFP, SFP+

Nettverksstandard

IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ad, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z

Ethernet-kobberkabelteknologi

10BASE-T, 100BASE-T, 1000BASE-T

Auto MDI/MDI-X

Ja

VLAN støtte

Ja

Virtuelle LAN-funksjoner

MAC address-based VLAN, Port-based VLAN, Voice VLAN

Antall VLAN

4093

Gjennomstrømming

130 Mpps

Størrelse på adressetabell

16000 oppføringer

Statisk ruting

Ja

Jumbo Frames-støtte

Ja

Jumbo rammer

9216

DHCP-funksjoner

DHCP client, DHCP relay, DHCP server

Access Control List (ACL)-utgang

256

Access Control List (ACL)-inngang

256

Sikkerhetsalgoritmer

HTTPS

Autentiseringstype

HWTACACS+, NAC SSH V2.0, RADIUS

Routerprotokoll

OSPF, OSPFv2, RIP-1, RIP-2

Rack-montering

Ja

Formfaktor

1U

Produktfarge

Sort

Temperatursensor

Ja

Innebygd prosessor

Ja

Prosessorfrekvens

1250 MHz

Minnetype

DRAM

Internminne

2000 MB

Flash-minne

2000 MB

Støynivå

51,4 dB

Strøm over Ethernet (PoE)

Ja

Driftstemperatur (T-T)

0 - 45 °C

Oppbevaringstemperaturomåde (Celsius)

-40 - 70 °C

Relativ luftfuktighet under drift (H-H)

10 - 85%

Bredde

441,9 mm

Dybde

309,8 mm

Høyde

44,5 mm

Vekt

5,02 kg

Samsvarssertifikat

RoHS

Sertifisering

UL-UL60950-1 (Second Edition), C-UL to CAN/CSA 22.2, No.60950-1 (Second Edition), TUV/GS to EN 60950-1 (Second Edition), CB-IEC60950-1 (Second Edition with all country deviations), EN 60825-1 (Second Edition) FCC 47CFR Part 15 Class A, EN 55022 Class A, ICES-003 Class A, VCCI Class A, AS/NZS CISPR 22 Class A, CISPR 22 Class A, EN 55024, EN 300386, CE

Harmonisert system (HS)-kode

85176990
