VAUXHALL CORSA D, ZAFIRA B AND ASTRA H CD RADIO SINGLE

DIN FACIA FASCIA SILVER PACKAGE

FASCIA SURROUND - SILVER

WIRING HARNESS

 REMOVAL KEYS

AERIAL ADAPTOR

Fascia Panel

These adaptors will allow you to remove your original factory

headunit and replace it with an aftermarket unit.

Facia Panels aid easy fitment and hold your new aftermarket unit

securely within your dash and are designed to keep the factory

fitted look of your vehicle.

Removal keys

Suitable for the removal of car stereos/head units that have four

holes for release keys

  Wiring Harness

The harness allows you to convert the factory wiring to the ISO connector of the aftermarket headunit.

Note: Red wire needs to connected to 12v Igniton feed.

Note: Orange wire on wiring harness needs to be connected to illumination wire on new unit if new unit requires it.

Note: Blue wire from aerial connection needs to be connected to remote output wire on new headunit or ignition supply wire.

Aerial Adaptor

 An aerial Adaptor is required when you replace the factory head unit with an after market unit.

FASCIA ADAPTOR WILL FIT THE FOLLOWING VEHICLES:

 ASTRA H: 2004-2010

ZAFIRA B: 2005-2014

CORSA D : 2006-2014

**PLEASE NOTE**

The above is just a guideline. There might be more than one kit available for your vehicle depending on your dash shape and connections. Please make sure that this is the correct kit for your vehicle by first checking that your vehicle is listed above and that the shape of the facia matches your dashboard.

 To ensure compatibility, we also recommend that the vehicle connector pictured above is compared to the actual connector on your vehicle. If you purchase this kit and it does not fit your vehicle then you have purchased the incorrect kit for your vehicle.
