An inverter, also called an inverter, is the very brain of a solar energy system. This applies both to large installations and to small ones intended for home use. Here we present a high-quality inverter for the slightly smaller property, SAKO SUNSEE 1kw MPPT solar hybrid inverter, with pure sine wave, of 1000 Watt and 12 Volt inverter intended for home solar systems with lots of built-in finesse, of which we would like to emphasize that it is equipped with several possibilities to connect you to it and control the entire system via communication devices: RS232/RS485/USB/

Ten quick ones:

1. Real MPPT charge controller built-in, 15%-20% higher than PWM charge controller, make maximum use of solar energy.

2. Pure sine wave, high frequency technology, wall design, lightweight and easy to use

3. Selectable input voltage range for household appliances and personal computers

4. Selectable charging current based on applications

5. Configurable AC/Solar input priority via LCD setting

6. Compatible with mains or generator power

7. Parallel operation with up to 6 units only available for 4KVA/5KVA

8. Auto restart while AC recovers, auto charge and switch,

9. Highly efficient DC-to-AC conversion. Minimizes energy losses and self-current consumption 10. All-round protection functions: Overload/short circuit protection/high voltage/low battery voltage/high temperature, etc.

Preferences

Brand : SAKO SUNSEE 1K

Type: DC/AC inverter

Product type: High frequency solar inverter

Use: Solar energy system

Nominal power: 1000VA/ 1000W

INPUT

Voltage: 230 VAC

Selectable voltage range: 90-280VAC (for personal computers), 170-280VAC (for household appliances)

Transport time 10ms (for personal computers) 20ms for home equipment

Output frequency: 50HZ/60HZ Automatic detection

Rated power: 20000VA

Power factor: 1 Power (Peak) 90%

Waveform: Pure sine wave

No load current: 1.25A

Battery voltage 12VDC

Low battery alarm voltage: 11.0VDC

Low battery without protection voltage: 10.5VDC

Low battery recovery voltage: 11.75VDC

Floating charge voltage: 13.5VDC

Overcharge protection: 16VDC

MPPT SOLAR CHARGERS & AC CHARGERS

Maximum PV array power: 480W

MPPT Range operation Vol: 100VDC

Standby power consumption: 15W

Maximum solar charging current: 40A

Maximum AC charging current : 20A

Maximum charging current: 60A

Maximum efficiency: 98%

BEST PANEL CONFIGURATION

Maximum generated from solar charger: 40A/ 480W

Rated power: 2000VA

Power factor: 1 Power (Peak) 90%

Waveform: Pure sine wave

No load current: 1.25A

Display: LCD+LED screen

Communication: RS232/RS485/USB/

Battery output voltage: 12VDC

Inverter efficiency: 98%

Transfer time: 10 ms

AC connection: 1 phase

Certificate: CE/IEC

Warranty period: 1 year

Output type: single

Size: 343 x 250 x 122mm

Weight: 5.8 Kg

Article number: 102974
