Align multicopter controller unit. Suitable for M480L / M690L or 4 rotors +, 4 rotors X, 6 rotors +, 6 rotors X...Multicopters
Brand new APS-M multicopter auto pilot system with superior performance through cutting edge IT technologies, utilizing high precision sensors and modern system control subroutines.
With higher performance, precision sensors and superior reliability platform.
Equipped with automatic return home function with remote activation ability from R/C transmitter. When RC transmitter signal is lost, multicopter will automatically fly back to home position.
APS-M provides 3 intelligent flight modes: CFO, HCL, and POI.
Provides real-time OSD flight data output function.
RoHS certified.
Compatible with PC and Bluetooth interface, could be easily adjust flight parameter and update firmware at any time.
Also fully support with Futaba, Spektrum and JR S. BUS/S.BUS and DSM2/DSMX/DSMJ/DMSS system.

Input Voltage:DC4.5V-8.4V.
Operating Current Consumption:less than250mA at 4.8V.
Operating Frequency:400Hz
Operating Temperature:-20degC - 65degC
Hovering Precision (Depending on Satellite Status):Horizontal +-1m, Vertical +-1m
Highest Flight Speed:Horizontal 15m/sec, Vertical 6m/sec
Maximum Altitude Restriction:700m above the takeoff point
Maximum Angular Speed:ALE 115deg /sec, ELE 115deg /sec, RUD 145deg /sec
Maximum Tilting Angle:30 degrees
Supports External Peripherals:G2 / G3 Gimbal, OSD+FPV Video Transmitter
Supports Multicopter Configurations: 4 rotors +, 4 rotors X, 6 rotors +, 6 rotors X, 8 rotors +, 8 rotors X
Dimension/Weight: 49x34.3x20mm/21.27g

* APS-M Multicopter Control Unit x 1
* APS-M Signal Wire Set ×1 (around 280mm)x 1
* APS-M Signal Wire x 3
* External Status LED x 1
* Multicopter GPS Sensor x 1
* USB Cable Set x 1
* External Status LED Sided Mounting Tape x 2
* APS-M Sided Mounting Tape x 2
* GPS Sided Mounting Tape x 2
