Ethernet WAN

Ja

Nettverksstandard

IEEE 802.1Q

Ethernet-grensesnittype

Gigabit Ethernet

Kablingsteknologi

10/100Base-T(X)

Ethernet LAN dataoverføringshastigheter

1000 Mbit/s

VLAN støtte

Ja

Strømningskontroll støtte

Ja

Multicast-støtte

Ja

Trafikkontroll

Ja

Mobilnettverksgenerasjon

Støttes ikke

Webbasert administrasjon

Ja

Quality of Service (QoS) støtte

Ja

Antall ethernets-/bredbåndstilkoblinger (RJ-45)

4

Gigabit Ethernet (kobber) antall porter

4

Antall USB-porter

1

USB-versjon

2.0/3.2 Gen 1 (3.1 Gen 1)

DHCP-klient

Ja

DHCP-server

Ja

Støttede protokoller

IPv4, IPv6, static routes, Open Shortest Path First (OSPF), Enhanced Interior Gateway Routing Protocol (EIGRP), Border Gateway Protocol (BGP), BGP Router Reflector, Intermediate System-to-Intermediate System (IS-IS), Multicast Internet Group Management Protocol Version 3 (IGMPv3), Protocol Independent Multicast Sparse Mode (PIM SM), PIM Source-Specific Multicast (SSM), Cisco Discovery Protocol, Internet Key Exchange (IKE), Access Control Lists (ACL), Dynamic Host Configuration Protocol (DHCP), DNS, VRRP, RADIUS, Authentication, Authorization, and Accounting (AAA), IPsec, Bidirectional Forwarding Detection (BFD), AppQoE, SNMP, Software defined Application Visibility and Control (SD-AVC), Layer 3 VPN, IPv6 for transport- side, symmetric NAT, NAT pools, NAT/PAT, split DNS,TCP optimization(BBR), 802.1Q, OMP, native VLAN, DTLS/TLS, DDOS protection, control plane protection, classification, prioritization, low latency queuing, remarking, shaping, scheduling, policing, IGMP v1/v2, PIM, service advertisement and insertion policy, SNMP, NTP, DNS client, Dynamic Host Configuration Protocol (DHCP), DHCP client, DHCP relay, syslog, SSH, SCP, Cflowd

Sikkerhetsalgoritmer

256-bit AES, SHA-1, SHA-2

Brannmur

Ja

Access Control List (ACL)/tilgangskontrolliste

Ja

Internminne

4000 MB

Internminnetype

DRAM

Produktfarge

Grå

LED-indikatorer

Ja

Krav til strømforsyning

30 W

Strømkildetype

DC

AC-inngangsspenning

100 - 240 V

AC-inngangsfrekvens

50 - 60 Hz

Utgangsstrøm

12 V

Driftstemperatur (T-T)

0 - 40 °C

Relativ luftfuktighet under drift (H-H)

0 - 95%

Driftshøyde

0 - 3000 m

Bredde

259 mm

Dybde

178 mm

Høyde

28 mm

Vekt

1,21 kg
